SRK-10

E-Switch
RoHS
RoHS RoHS compliant
Package /
Category Switches / DIP Switches
Description SWITCH ROTARY DIP BCD 100MA 5V
PDF
/
Inventory: 7924
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Height Above Board 0.256 6.50mm
Actuator Length 0m
Length 0.393 10.00mm

Technical

Actuator Level Flush, Recessed
Washable Yes
Switch Type ROTARY CODED SWITCH
Max Voltage Rating (DC) 5V
Throw Configuration SP10T
Electrical Life 15,000 Cycles
Contact Resistance 100mOhm
Circuit BCD
Actuator Type Rotary for Tool
Voltage - Rated AC 5V
Termination Style PC Pin
Contact Finish Gold
Current Rating 100mA
Terminal Pitch 2.54mm
Orientation Straight
Pitch 0.100 2.54mm Full
Voltage - Rated DC 5V
Number of Positions 10
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series SRK
Published 2011
Packaging Tube
Operating Temperature -10°C~60°C

Physical

Actuator Material Polyacetal
Body Material Polyphenylene Sulfide (PPS)
Mounting Type Through Hole
Mount Through Hole
Contact Material Glass Fabric Epoxy Resin

Supply Chain

Factory Lead Time 10 Weeks
