KAS2104E
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
SWITCH SLIDE DIP SPST 25MA 24V
PDF
/
Buying Options
Total Price: USD $1.09
Unit Price: USD $1.0912
≥1 USD $1.0912
≥10 USD $1.06128
≥100 USD $0.96514
≥500 USD $0.83857
≥1000 USD $0.7689
Inventory: 5050
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height Above Board 0.390 9.90mm
Body Height 0.39mm
Length 0.454 11.52mm
Technical
Actuator Level Raised
Washable No
Contact Function ON-OFF
PCB Hole Count 8
Number of Switch Sections 4
Switch Type SLIDE DIP SWITCH
Mechanical Life 2,000 Cycles
Electrical Life 2,000 Cycles
Dielectric Withstanding Voltage 500VRMS V
Sealing EPOXY
Contact Current(DC)-Max 0.025A
Insulation Resistance 100000000Ohm
Contact Resistance 0.05mOhm
Circuit SPST
Actuator Type Slide (Standard)
Termination Style PC Pin
Contact Finish Gold
Current Rating 25mA
Pitch 0.100 2.54mm Full
Voltage - Rated DC 24V
HTS Code 8536.50.90.65
Voltage - Rated 24VDC
Number of Positions 4
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series KAS
Published 2003
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Body Material Polybutylene Terephthalate (PBT), Glass Filled
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 11 Weeks
