KAS2103ET
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
DIP Switches / SIP Switches 3 PositionR/A PC Pin Extended Tape Sealed
PDF
/
Buying Options
Total Price: USD $1.09
Unit Price: USD $1.0912
≥1 USD $1.0912
≥10 USD $1.06128
≥100 USD $0.899712
≥500 USD $0.838552
≥1000 USD $0.768909
Inventory: 1203
Minimum: 1
-
+
Technical Details
Technical
Mechanical Life 2,000 Cycles
Switch Type SLIDE DIP SWITCH
PCB Hole Count 6
Washable Yes
Actuator Level Raised
Max Voltage Rating (DC) 24V
Electrical Life 2,000 Cycles
Dielectric Withstanding Voltage 500VRMS V
Contact Current(DC)-Max 0.025A
Insulation Resistance 100000000Ohm
Contact Resistance 50mOhm
Circuit SPST
Actuator Type Slide (Standard)
Body Breadth 9.906 mm
Termination Style PC Pin
Contact Finish Gold
Current Rating 25mA
Terminal Pitch 2.54mm
Orientation Right Angle
Pitch 0.100 2.54mm Full
Voltage - Rated DC 24V
Additional Feature EXTENDED ACTUATOR
Voltage - Rated 24VDC
Number of Positions 3
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Tape Seal
Series KAS
Published 2006
Packaging Bulk
Operating Temperature -40°C~85°C
Physical
Actuator Material Glass, Polyester
Body Material Polybutylene Terephthalate (PBT), Glass Filled
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 11 Weeks
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height Above Board 0.390 9.90mm
Actuator Length 1mm
Length 0.354 8.99mm
