KAS1104RT
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
SWITCH SLIDE DIP SPST 25MA 24V
PDF
/
Buying Options
Total Price: USD $0.98
Unit Price: USD $0.9768
≥1 USD $0.9768
≥10 USD $0.93896
≥100 USD $0.882482
≥500 USD $0.762291
≥1000 USD $0.694681
≥3000 USD $0.661091
Inventory: 2117
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Above Board 0.236 6.00mm
Length 0.454 11.52mm
Technical
Actuator Level Flush, Recessed
Washable Yes
PCB Hole Count 8
Switch Type SLIDE DIP SWITCH
Mechanical Life 2,000 Cycles
Electrical Life 2,000 Cycles
Dielectric Withstanding Voltage 500VRMS V
Contact Current(DC)-Max 0.025A
Insulation Resistance 100000000Ohm
Contact Resistance 0.1mOhm
Circuit SPST
Actuator Type Slide (Standard)
Body Breadth 9.906 mm
Termination Style PC Pin
Contact Finish Gold
Current Rating 25mA
Pitch 0.100 2.54mm Full
Voltage - Rated DC 24V
Voltage - Rated 24VDC
Number of Positions 4
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Tape Seal
Series KAS
Published 2004
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Body Material Polybutylene Terephthalate (PBT), Glass Filled
Mounting Type Through Hole
Mount Through Hole
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 11 Weeks
