KAR05LAGT

E-Switch
RoHS
/
Package /
Category Switches / DIP Switches
Description Piano KAR 5 Through Hole Right Angle Dip Switch 7.4422mm 25mA 24VDC 0.1mOhm
PDF
/
Inventory: 6500
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Material Copper Alloy
Mount Through Hole
Mounting Type Through Hole, Right Angle
Insulation Material POLYPHENYLENE SULPHIDE
Body Material Polyphenylene Sulfide (PPS)
Terminal Material BRASS

Technical

Operating Temperature -30°C~85°C
Packaging Tube
Published 2006
Series KAR
Feature Process Sealed
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Number of Positions 5
Voltage - Rated 24VDC
Voltage - Rated DC 24V
Pitch 0.100 2.54mm Full
Current Rating 25mA
Contact Finish Gold
Termination Style PC Pin
Actuator Type Piano
Circuit SPST
Contact Resistance 0.1mOhm
Insulation Resistance 1000000000Ohm
Mechanical Life 2,000 Cycles
Number of Switch Sections 5
PCB Hole Count 10
Washable Yes
Actuator Level Raised

Dimensions

Length 0.590 14.99mm
Body Height 7.4422mm
Height Above Board 0.287 7.30mm

Compliance

RoHS Status RoHS Compliant
