KAJ12TGGT

E-Switch
RoHS
/
Package /
Category Switches / DIP Switches
Description SWITCH SLIDE DIP SPST 25MA 24V
PDF
/
Buying Options
Total Price: USD $2.9
Unit Price: USD $2.900196
≥1 USD $2.900196
≥192 USD $1.157978
≥496 USD $1.118591
≥992 USD $1.10021
Inventory: 4217
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Height Above Board 0.140 3.55mm
Body Height 3.2mm
Length 1.200 30.48mm

Technical

Actuator Level Flush, Recessed
Washable Yes
Number of Switch Sections 12
Switch Type SLIDE DIP SWITCH
Mechanical Life 2,000 Cycles
Electrical Life 2,000 Cycles
Contact Current(DC)-Max 0.025A
Circuit SPST
Actuator Type Slide (Standard)
Termination Style Gull Wing
Contact Finish Gold
Current Rating 25mA
Pitch 0.100 2.54mm Full
Voltage - Rated DC 24V
HTS Code 8536.50.90.65
Additional Feature LOW PROFILE
Voltage - Rated 24VDC
Number of Positions 12
ECCN Code EAR99
Termination Gull Wing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature Tape Seal
JESD-609 Code e4
Series KAJ
Published 2007
Packaging Tube
Operating Temperature -40°C~85°C

Physical

Body Material Polyphenylene Sulfide (PPS)
Mounting Type Surface Mount
Mount Surface Mount
Contact Material Copper Alloy
