KAJ12SHGT
RoHS
/
Package /
Category Switches / DIP Switches
Description
SWITCH SLIDE DIP SPST 25MA 24V
PDF
/
Inventory: 2405
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Above Board 0.142 3.60mm
Body Height 3.6mm
Length 1.200 30.48mm
Technical
Actuator Level Flush, Recessed
Washable No
Number of Switch Sections 12
Switch Type SLIDE DIP SWITCH
Mechanical Life 2,000 Cycles
Electrical Life 2,000 Cycles
Contact Current(DC)-Max 0.025A
Circuit SPST
Actuator Type Slide (Standard)
Termination Style PC Pin
Contact Finish Gold
Current Rating 25mA
Pitch 0.100 2.54mm Full
Voltage - Rated DC 24V
HTS Code 8536.50.90.65
Additional Feature LOW PROFILE
Voltage - Rated 24VDC
Number of Positions 12
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Series KAJ
Published 2007
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Body Material Polyphenylene Sulfide (PPS)
Mounting Type Through Hole
Mount Through Hole
Contact Material Copper Alloy
