KAJ07SHGT

E-Switch
RoHS
/
Package /
Category Switches / DIP Switches
Description Slide (Standard) KAJ 7 Through Hole Dip Switch 3.6mm 0.025A 24VDC -40C~85C
PDF
/
Inventory: 7398
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Height Above Board 0.142 3.60mm
Body Height 3.6mm
Length 0.700 17.78mm

Technical

Actuator Level Flush, Recessed
Washable No
Number of Switch Sections 7
Switch Type SLIDE DIP SWITCH
Mechanical Life 2,000 Cycles
Electrical Life 2,000 Cycles
Contact Current(DC)-Max 0.025A
Circuit SPST
Actuator Type Slide (Standard)
Termination Style PC Pin
Contact Finish Gold
Current Rating 25mA
Pitch 0.100 2.54mm Full
Voltage - Rated DC 24V
HTS Code 8536.50.90.65
Additional Feature LOW PROFILE
Voltage - Rated 24VDC
Number of Positions 7
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Series KAJ
Published 2007
Packaging Tube
Operating Temperature -40°C~85°C

Physical

Body Material Polyphenylene Sulfide (PPS)
Mounting Type Through Hole
Mount Through Hole
Contact Material Copper Alloy
