KAJ06SGGR
RoHS
/
Package /
Category Switches / DIP Switches
Description
SWITCH SLIDE DIP SPST 25MA 24V
PDF
/
Inventory: 1434
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Above Board 0.140 3.55mm
Body Height 3.2mm
Length 0.600 15.24mm
Technical
Actuator Level Flush, Recessed
Washable No
Number of Switch Sections 6
Switch Type SLIDE DIP SWITCH
Mechanical Life 2,000 Cycles
Electrical Life 2,000 Cycles
Contact Current(DC)-Max 0.025A
Circuit SPST
Actuator Type Slide (Standard)
Termination Style Gull Wing
Contact Finish Gold
Current Rating 25mA
Packing Method TAPE AND REEL
Pitch 0.100 2.54mm Full
Voltage - Rated DC 24V
Additional Feature LOW PROFILE
Voltage - Rated 24VDC
Number of Positions 6
ECCN Code EAR99
Termination Gull Wing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Series KAJ
Published 2007
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Body Material Polyphenylene Sulfide (PPS)
Mounting Type Surface Mount
Mount Surface Mount
Contact Material Copper Alloy
