KAJ02LGGT

E-Switch
RoHS
/
Package /
Category Switches / DIP Switches
Description SWITCH SLIDE DIP SPST 25MA 24V
PDF
/
Inventory: 4272
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant

Dimensions

Height Above Board 0.163 4.15mm
Actuator Length 600μm
Length 0.200 5.08mm

Technical

Body Color BLACK
Actuator Level Raised
Washable No
Actuator Color WHITE
Number of Switch Sections 2
Switch Type SLIDE DIP SWITCH
Mechanical Life 2,000 Cycles
Max Voltage Rating (DC) 24V
Electrical Life 2,000 Cycles
Dielectric Withstanding Voltage 500VRMS V
Insulation Resistance 100000000Ohm
Contact Resistance 50mOhm
Circuit SPST
Actuator Type Slide (Standard)
Body Breadth 5.08 mm
Termination Style Gull Wing
Contact Finish Gold
Terminal Pitch 2.54mm
Orientation Straight
Pitch 0.100 2.54mm Full
Current Rating (Amps) 25mA
HTS Code 8536.50.90.65
Voltage - Rated 24VDC
Number of Positions 2
ECCN Code EAR99
Termination Gull Wing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series KAJ
Published 2002
Packaging Tube
Operating Temperature -40°C~85°C

Physical

Terminal Material BRASS
Body Material Polyphenylene Sulfide (PPS)
Housing Material POLYPHENYLENE SULPHIDE
Insulation Material POLYPHENYLENE SULPHIDE
Mounting Type Surface Mount
Mount Surface Mount
Contact Material Copper Alloy
