KAE06TGGR
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
SWITCH SLIDE DIP SPST 25MA 24V
PDF
/
Inventory: 4769
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Contact Material Copper
Mounting Type Surface Mount
Surface Mount NO
Terminal Material BRASS
Technical
Operating Temperature -20°C~85°C
Packaging Tape & Reel (TR)
Published 2012
Series KAE
JESD-609 Code e4
Feature Tape Seal
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Number of Positions 6
Voltage - Rated 24VDC
Additional Feature TAPE AND REEL PACKAGING
Current Rating (Amps) 25mA
Pitch 0.100 2.54mm Full
Packing Method TR
Contact Finish Gold
Termination Style Gull Wing
Actuator Type Slide (Standard)
Circuit SPST
Contact Resistance 0.05mOhm
Insulation Resistance 100000000Ohm
Contact Current(DC)-Max 0.025A
Contact Voltage(DC)-Max 24V
Dielectric Withstanding Voltage 500VAC V
Electrical Life 2,000 Cycles
Mechanical Life 2,000 Cycles
Switch Type SLIDE DIP SWITCH
Number of Switch Sections 6
Washable Yes
Actuator Level Flush, Recessed
Dimensions
Length 0.641 16.28mm
Body Height 3.05mm
Height Above Board 0.148 3.75mm
Compliance
RoHS Status ROHS3 Compliant
