KAE02TGGR
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
SWITCH SLIDE DIP SPST 25MA 24V
PDF
/
Buying Options
Total Price: USD $2.3
Unit Price: USD $2.296262
≥1 USD $2.296262
≥200 USD $0.916404
≥500 USD $0.886208
≥900 USD $0.870453
Inventory: 4603
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height Above Board 0.148 3.75mm
Length 0.241 6.12mm
Technical
Actuator Level Flush, Recessed
Washable Yes
Mechanical Life 2,000 Cycles
Electrical Life 2,000 Cycles
Dielectric Withstanding Voltage 500VAC V
Insulation Resistance 100000000Ohm
Contact Resistance 0.05mOhm
Circuit SPST
Actuator Type Slide (Standard)
Termination Style Gull Wing
Contact Finish Gold
Pitch 0.100 2.54mm Full
Current Rating (Amps) 25mA
Additional Feature TAPE AND REEL PACKAGING
Voltage - Rated 24VDC
Number of Positions 2
ECCN Code EAR99
Termination Gull Wing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Tape Seal
Series KAE
Published 2012
Packaging Tape & Reel (TR)
Operating Temperature -20°C~85°C
Physical
Terminal Material BRASS
Mounting Type Surface Mount
Mount Surface Mount
Contact Material Copper
Supply Chain
Factory Lead Time 11 Weeks
