DR4AH-16R-B
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Rotary with Shaft DR 16 Through Hole Right Angle Dip Switch 6.6294mm 25mA 250VAC V 22.5deg
PDF
/
Inventory: 9427
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Contact Material Copper
Mount Through Hole
Mounting Type Through Hole, Right Angle
Body Material Polyamide (PA), Nylon
Terminal Material BRASS
Technical
Operating Temperature -25°C~80°C
Packaging Tube
Published 2011
Series DR
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Number of Positions 16
Voltage - Rated DC 24V
Pitch 0.100 2.54mm Full
Current Rating 25mA
Contact Finish Gold
Termination Style PC Pin
Voltage - Rated AC 24V
Actuator Type Rotary with Shaft
Circuit Hexadecimal
Contact Resistance 0.1mOhm
Insulation Resistance 100000000Ohm
Dielectric Withstanding Voltage 250VAC V
Electrical Life 15,000 Cycles
Switch Type ROTARY SWITCH
Index Angle 22.5 deg
PCB Hole Count 5
Washable No
Actuator Level Raised
Dimensions
Length 0.386 9.80mm
Body Height 6.6294mm
Height Above Board 0.390 9.90mm
Compliance
RoHS Status ROHS3 Compliant
