DR3M-16R-TR
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
SWITCH ROTARY DIP HEX 25MA 24V
PDF
/
Buying Options
Total Price: USD $4.34
Unit Price: USD $4.335196
≥1 USD $4.335196
≥200 USD $1.730402
≥750 USD $1.672635
≥1500 USD $1.643751
Inventory: 4829
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Above Board 0.177 4.50mm
Body Height 4.699mm
Length 0.386 9.80mm
Technical
Body Color BLACK
Actuator Level Flush, Recessed
Washable No
Actuator Color WHITE
PCB Hole Count 6
Switch Type ROTARY CODED SWITCH
Electrical Life 15,000 Cycles
Dielectric Withstanding Voltage 250VAC V
Contact Current(DC)-Max 0.025A
Insulation Resistance 100000000Ohm
Contact Resistance 0.2mOhm
Circuit Hexadecimal
Actuator Type Rotary for Tool
Body Breadth 9.8044 mm
Termination Style Gull Wing
Contact Finish Gold
Current Rating 25mA
Pitch 0.100 2.54mm Full
Voltage - Rated DC 24V
Voltage - Rated 24VDC
Number of Positions 16
ECCN Code EAR99
Termination Gull Wing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series DR
Published 2012
Packaging Tape & Reel (TR)
Operating Temperature -25°C~80°C
Physical
Terminal Material BRASS
Body Material Polyamide (PA), Nylon
Mounting Type Surface Mount
Mount Surface Mount
Contact Material Copper
Supply Chain
Factory Lead Time 11 Weeks
