DR3M-10R-B
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
SWITCH ROTARY DIP BCD 25MA 24V
PDF
/
Buying Options
Total Price: USD $4.24
Unit Price: USD $4.239354
≥1 USD $4.239354
≥192 USD $1.692328
≥480 USD $1.635873
≥1008 USD $1.608303
Inventory: 7712
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Above Board 0.177 4.50mm
Body Height 4.4958mm
Length 0.386 9.80mm
Technical
Actuator Level Flush, Recessed
Washable No
PCB Hole Count 6
Index Angle 36 deg
Switch Type ROTARY SWITCH
Electrical Life 15,000 Cycles
Dielectric Withstanding Voltage 250VAC V
Contact Resistance 0.1mOhm
Circuit BCD
Actuator Type Rotary for Tool
Voltage - Rated AC 24V
Termination Style Gull Wing
Contact Finish Gold
Current Rating 25mA
Pitch 0.100 2.54mm Full
Voltage - Rated DC 24V
Number of Positions 10
Termination Gull Wing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series DR
Published 2011
Packaging Tube
Operating Temperature -25°C~80°C
Physical
Terminal Material BRASS
Body Material Polyamide (PA), Nylon
Mounting Type Surface Mount
Mount Surface Mount
Contact Material Copper
Supply Chain
Factory Lead Time 11 Weeks
