DS02C-254-1L-07BE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
DIP SWITCH, SPST, 2.54 PITCH, RA
PDF
/
Buying Options
Total Price: USD $1.03
Unit Price: USD $1.0296
≥1 USD $1.0296
≥10 USD $0.9933
≥100 USD $0.933715
≥500 USD $0.80652
≥1000 USD $0.735002
≥3000 USD $0.683346
Inventory: 122
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Above Board 0.378 9.60mm
Length 0.762 19.35mm
Technical
Actuator Level Raised
Washable No
Electrical Life 2,000 Cycles
Circuit SPST
Actuator Type Piano
Termination Style PC Pin
Contact Finish Gold
Pitch 0.100 2.54mm Full
Current Rating (Amps) 25mA
Voltage - Rated 24VDC
Number of Positions 7
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series DS02-254
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Body Material Polybutylene Terephthalate (PBT)
Mounting Type Through Hole, Right Angle
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 8 Weeks
