DS01C-254-S-07BE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Slide (Standard) DS01-254 7 Through Hole Dip Switch 0.264 6.70mm 25mA 24VDC -40C~85C
PDF
/
Buying Options
Total Price: USD $0.45
Unit Price: USD $0.4488
≥1 USD $0.4488
≥10 USD $0.429
≥100 USD $0.412315
≥500 USD $0.35794
≥1000 USD $0.326603
≥3000 USD $0.303494
Inventory: 337
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Copper Alloy
Mounting Type Through Hole
Body Material Polybutylene Terephthalate (PBT)
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Series DS01-254
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Positions 7
Voltage - Rated 24VDC
Current Rating (Amps) 25mA
Pitch 0.100 2.54mm Full
Contact Finish Gold
Termination Style PC Pin
Actuator Type Slide (Standard)
Circuit SPST
Electrical Life 2,000 Cycles
Washable No
Actuator Level Raised
Dimensions
Length 0.756 19.20mm
Height Above Board 0.264 6.70mm
Compliance
RoHS Status RoHS Compliant
