219-7LPSJR
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Slide (Standard) 219 7 Surface Mount Dip Switch 3.8mm 0.1A 20V -55C~85C
PDF
/
Buying Options
Total Price: USD $1.69
Unit Price: USD $1.691015
≥1 USD $1.691015
≥200 USD $0.674831
≥500 USD $0.652511
≥1000 USD $0.640695
Inventory: 2836
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Beryllium Copper
Mounting Type Surface Mount
Surface Mount NO
Technical
Operating Temperature -55°C~85°C
Packaging Tape & Reel (TR)
Published 2008
Series 219
JESD-609 Code e3
Feature Epoxy Sealed Terminals
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Number of Positions 7
Terminal Finish Tin (Sn)
Voltage - Rated 20VDC
HTS Code 8536.50.90.65
Current Rating (Amps) 100mA
Pitch 0.100 2.54mm Full
Packing Method TAPE AND REEL
Contact Finish Gold
Termination Style J Lead
Actuator Type Slide (Standard)
Circuit SPST
Contact Current(DC)-Max 0.1A
Sealing BOTTOM SEALED
Contact Voltage(DC)-Max 20V
Electrical Life 2,000 Cycles
Switch Type SLIDE DIP SWITCH
Number of Switch Sections 7
Washable No
Actuator Level Flush, Recessed
Dimensions
Length 0.758 19.25mm
Body Height 3.8mm
Height Above Board 0.200 5.08mm
Compliance
RoHS Status RoHS Compliant
