219-3LPSRF
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Slide (Standard) 219 3 Surface Mount Dip Switch 0.160 4.06mm 0.1A 20V -55C~85C
PDF
/
Inventory: 3773
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Beryllium Copper
Mounting Type Surface Mount
Surface Mount NO
Technical
Operating Temperature -55°C~85°C
Packaging Tape & Reel (TR)
Published 2008
Series 219
JESD-609 Code e3
Feature Epoxy Sealed Terminals
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Number of Positions 3
Terminal Finish Tin (Sn)
Voltage - Rated 20VDC
Current Rating (Amps) 100mA
Pitch 0.100 2.54mm Full
Packing Method TAPE AND REEL
Contact Finish Gold
Termination Style Gull Wing
Body Breadth 6.7 mm
Actuator Type Slide (Standard)
Circuit SPST
Contact Current(DC)-Max 0.1A
Sealing BOTTOM SEALED
Contact Voltage(DC)-Max 20V
Electrical Life 2,000 Cycles
Switch Type SLIDE DIP SWITCH
Number of Switch Sections 3
Washable No
Actuator Level Flush, Recessed
Dimensions
Length 0.358 9.09mm
Height Above Board 0.160 4.06mm
Compliance
RoHS Status RoHS Compliant
