219-2LPSRF
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Slide (Standard) 219 2 Surface Mount Dip Switch 3.8mm 0.1A 20VDC -55C~85C
PDF
/
Buying Options
Total Price: USD $0.96
Unit Price: USD $0.95973
≥1 USD $0.95973
≥200 USD $0.383367
≥500 USD $0.370238
≥1000 USD $0.363673
Inventory: 5939
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Above Board 0.160 4.06mm
Body Height 3.8mm
Length 0.258 6.55mm
Technical
Actuator Level Flush, Recessed
Washable No
Number of Switch Sections 2
Switch Type SLIDE DIP SWITCH
Electrical Life 2,000 Cycles
Sealing BOTTOM SEALED
Contact Current(DC)-Max 0.1A
Circuit SPST
Actuator Type Slide (Standard)
Body Breadth 6.55 mm
Termination Style Gull Wing
Contact Finish Gold
Packing Method TAPE AND REEL
Pitch 0.100 2.54mm Full
Current Rating (Amps) 100mA
HTS Code 8536.50.90.65
Voltage - Rated 20VDC
Terminal Finish Tin (Sn)
Number of Positions 2
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Epoxy Sealed Terminals
JESD-609 Code e3
Series 219
Published 2008
Packaging Tape & Reel (TR)
Operating Temperature -55°C~85°C
Physical
Surface Mount NO
Mounting Type Surface Mount
Contact Material Beryllium Copper
Supply Chain
Factory Lead Time 8 Weeks
