219-10MSRF
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Switch DIP OFF ON SPST 10 Extended Slide 0.1A 20VDC Gull Wing SMD T/R
PDF
/
Buying Options
Total Price: USD $1.9
Unit Price: USD $1.901079
≥1 USD $1.901079
≥200 USD $0.758856
≥500 USD $0.733911
≥1000 USD $0.720782
Inventory: 6652
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Beryllium Copper
Mounting Type Surface Mount
Surface Mount NO
Technical
Operating Temperature -55°C~85°C
Packaging Tape & Reel (TR)
Published 2008
Series 219
JESD-609 Code e4
Feature Epoxy Sealed Terminals
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Number of Positions 10
Voltage - Rated 20VDC
HTS Code 8536.50.90.65
Current Rating (Amps) 100mA
Pitch 0.100 2.54mm Full
Packing Method TAPE AND REEL
Contact Finish Gold
Termination Style Gull Wing
Body Breadth 6.7 mm
Actuator Type Slide (Standard)
Circuit SPST
Contact Current(DC)-Max 0.1A
Sealing BOTTOM SEALED
Contact Voltage(DC)-Max 20V
Electrical Life 2,000 Cycles
Switch Type SLIDE DIP SWITCH
Number of Switch Sections 10
Washable No
Actuator Level Raised
Dimensions
Length 1.058 26.87mm
Body Height 3.8mm
Height Above Board 0.170 4.33mm
Compliance
RoHS Status RoHS Compliant
