218-8LPSJR
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Slide (Standard) 218 8 Surface Mount Dip Switch 2.7mm 0.025A 24V -55C~85C
PDF
/
Inventory: 8453
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Above Board 0.106 2.70mm
Body Height 2.7mm
Length 0.446 11.33mm
Technical
Actuator Level Flush, Recessed
Washable No
Number of Switch Sections 8
Switch Type SLIDE DIP SWITCH
Electrical Life 1,000 Cycles
Contact Voltage(DC)-Max 24V
Sealing BOTTOM SEALED
Contact Current(DC)-Max 0.025A
Circuit SPST
Actuator Type Slide (Standard)
Termination Style J Lead
Contact Finish Gold
Packing Method TAPE AND REEL
Pitch 0.050 1.27mm Half
Current Rating (Amps) 25mA
Voltage - Rated 24VDC
Number of Positions 8
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Epoxy Sealed Terminals
Series 218
Published 2008
Packaging Tape & Reel (TR)
Operating Temperature -55°C~85°C
Physical
Surface Mount NO
Mounting Type Surface Mount
Contact Material Beryllium Copper
Supply Chain
Factory Lead Time 8 Weeks
