218-6LPSJR
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Slide (Standard) 218 6 Surface Mount Dip Switch 2.7mm 0.025A 24V -55C~85C
PDF
/
Buying Options
Total Price: USD $2.15
Unit Price: USD $2.146592
≥1 USD $2.146592
≥200 USD $0.857324
≥500 USD $0.82844
≥1000 USD $0.813998
Inventory: 4565
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Above Board 0.106 2.70mm
Body Height 2.7mm
Length 0.346 8.79mm
Technical
Actuator Level Flush, Recessed
Washable No
Number of Switch Sections 6
Switch Type SLIDE DIP SWITCH
Electrical Life 1,000 Cycles
Contact Voltage(DC)-Max 24V
Sealing BOTTOM SEALED
Contact Current(DC)-Max 0.025A
Circuit SPST
Actuator Type Slide (Standard)
Body Breadth 5.8 mm
Termination Style J Lead
Contact Finish Gold
Packing Method TAPE AND REEL
Pitch 0.050 1.27mm Half
Current Rating (Amps) 25mA
Voltage - Rated 24VDC
Number of Positions 6
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Epoxy Sealed Terminals
Series 218
Published 2008
Packaging Tape & Reel (TR)
Operating Temperature -55°C~85°C
Physical
Surface Mount NO
Mounting Type Surface Mount
Contact Material Beryllium Copper
Supply Chain
Factory Lead Time 8 Weeks
