218-12LPSTJRF
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Slide (Standard) 218 12 Surface Mount Dip Switch 2.7mm 0.025A 24V -55C~85C
PDF
/
Buying Options
Total Price: USD $3.13
Unit Price: USD $3.127328
≥1 USD $3.127328
≥200 USD $1.248568
≥500 USD $1.206555
≥1000 USD $1.185549
Inventory: 7857
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Above Board 0.106 2.70mm
Body Height 2.7mm
Length 0.646 16.41mm
Technical
Actuator Level Flush, Recessed
Washable Yes
Number of Switch Sections 12
Switch Type SLIDE DIP SWITCH
Electrical Life 1,000 Cycles
Contact Voltage(DC)-Max 24V
Sealing BOTTOM SEALED; TOP TAPE SEALED
Contact Current(DC)-Max 0.025A
Circuit SPST
Actuator Type Slide (Standard)
Body Breadth 5.8 mm
Termination Style J Lead
Contact Finish Gold
Packing Method TAPE AND REEL
Pitch 0.050 1.27mm Half
Current Rating (Amps) 25mA
HTS Code 8536.50.90.65
Voltage - Rated 24VDC
Number of Positions 12
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Epoxy Sealed Terminals, Tape Seal
Series 218
Published 2008
Packaging Tape & Reel (TR)
Operating Temperature -55°C~85°C
Physical
Surface Mount NO
Mounting Type Surface Mount
Contact Material Beryllium Copper
Supply Chain
Factory Lead Time 8 Weeks
