218-12LPST
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
SWITCH SLIDE DIP SPST 25MA 24V
PDF
/
Buying Options
Total Price: USD $1.69
Unit Price: USD $1.6896
≥1 USD $1.6896
≥10 USD $1.6412
≥100 USD $1.49307
≥500 USD $1.29712
≥1000 USD $1.175486
≥3000 USD $1.09443
Inventory: 857
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Above Board 0.104 2.65mm
Body Height 2.65mm
Length 0.646 16.41mm
Technical
Actuator Level Flush, Recessed
Washable Yes
Number of Switch Sections 12
Switch Type SLIDE DIP SWITCH
Electrical Life 1,000 Cycles
Contact Voltage(DC)-Max 24V
Sealing BOTTOM SEALED; TOP TAPE SEALED
Contact Current(DC)-Max 0.025A
Circuit SPST
Actuator Type Slide (Standard)
Body Breadth 5.8 mm
Termination Style Gull Wing
Contact Finish Gold
Pitch 0.050 1.27mm Half
Current Rating (Amps) 25mA
HTS Code 8536.50.90.65
Voltage - Rated 24VDC
Number of Positions 12
ECCN Code EAR99
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Feature Epoxy Sealed Terminals, Tape Seal
JESD-609 Code e4
Series 218
Published 2008
Packaging Tube
Operating Temperature -55°C~85°C
Physical
Surface Mount NO
Mounting Type Surface Mount
Contact Material Beryllium Copper
Supply Chain
Factory Lead Time 8 Weeks
