218-10LPSR
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Slide (Standard) 218 10 Surface Mount Dip Switch 2.65mm 0.025A 24V -55C~85C
PDF
/
Inventory: 5427
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Beryllium Copper
Mounting Type Surface Mount
Surface Mount NO
Technical
Operating Temperature -55°C~85°C
Packaging Tape & Reel (TR)
Published 2008
Series 218
JESD-609 Code e4
Feature Epoxy Sealed Terminals
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Number of Positions 10
Voltage - Rated 24VDC
HTS Code 8536.50.90.65
Current Rating (Amps) 25mA
Pitch 0.050 1.27mm Half
Packing Method TAPE AND REEL
Contact Finish Gold
Termination Style Gull Wing
Body Breadth 5.8 mm
Actuator Type Slide (Standard)
Circuit SPST
Contact Current(DC)-Max 0.025A
Sealing BOTTOM SEALED
Contact Voltage(DC)-Max 24V
Electrical Life 1,000 Cycles
Switch Type SLIDE DIP SWITCH
Number of Switch Sections 10
Washable No
Actuator Level Flush, Recessed
Dimensions
Length 0.546 13.87mm
Body Height 2.65mm
Height Above Board 0.104 2.65mm
Compliance
RoHS Status RoHS Compliant
