210-7LPSTFD
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Slide (Standard) 210 7 Through Hole Dip Switch 3.8mm 0.1A 20V -40C~85C
PDF
/
Buying Options
Total Price: USD $1.14
Unit Price: USD $1.143536
≥1 USD $1.143536
≥200 USD $0.456889
≥500 USD $0.441134
≥1000 USD $0.433257
Inventory: 4270
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Beryllium Copper
Mounting Type Through Hole
Surface Mount NO
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2016
Series 210
Feature Epoxy Sealed Terminals, Tape Seal
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Number of Positions 7
Voltage - Rated 20VDC
HTS Code 8536.50.90.65
Current Rating (Amps) 100mA
Pitch 0.100 2.54mm Full
Contact Finish Gold
Termination Style PC Pin
Actuator Type Slide (Standard)
Circuit SPST
Contact Current(DC)-Max 0.1A
Sealing BOTTOM SEALED; TOP TAPE SEALED
Contact Voltage(DC)-Max 20V
Electrical Life 1,000 Cycles
Switch Type SLIDE DIP SWITCH
Number of Switch Sections 7
Washable Yes
Actuator Level Flush, Recessed
Dimensions
Length 0.758 19.25mm
Body Height 3.8mm
Height Above Board 0.180 4.57mm
Compliance
RoHS Status RoHS Compliant
