210-6LPSTF
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Slide (Standard) 210 6 Through Hole Dip Switch 3.8mm 0.1A 20V -40C~85C
PDF
/
Inventory: 2592
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Above Board 0.180 4.57mm
Body Height 3.8mm
Length 0.658 16.71mm
Technical
Actuator Level Flush, Recessed
Washable Yes
Number of Switch Sections 6
Switch Type SLIDE DIP SWITCH
Electrical Life 1,000 Cycles
Contact Voltage(DC)-Max 20V
Sealing BOTTOM SEALED; TOP TAPE SEALED
Contact Current(DC)-Max 0.1A
Circuit SPST
Actuator Type Slide (Standard)
Termination Style PC Pin
Contact Finish Gold
Pitch 0.100 2.54mm Full
Current Rating (Amps) 100mA
Voltage - Rated 20VDC
Number of Positions 6
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Epoxy Sealed Terminals, Tape Seal
Series 210
Published 2016
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Surface Mount NO
Mounting Type Through Hole
Contact Material Beryllium Copper
Supply Chain
Factory Lead Time 8 Weeks
