210-4MSTFD
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Slide (Standard) 210 4 Through Hole Dip Switch 3.8mm 0.1A 20V -40C~85C
PDF
/
Buying Options
Total Price: USD $0.87
Unit Price: USD $0.870453
≥1 USD $0.870453
≥180 USD $0.347919
≥495 USD $0.336102
≥990 USD $0.330851
Inventory: 3984
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Beryllium Copper
Mounting Type Through Hole
Surface Mount NO
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2016
Series 210
Feature Epoxy Sealed Terminals, Tape Seal
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Number of Positions 4
Voltage - Rated 20VDC
HTS Code 8536.50.90.65
Current Rating (Amps) 100mA
Pitch 0.100 2.54mm Full
Contact Finish Gold
Termination Style PC Pin
Body Breadth 6.7 mm
Actuator Type Slide (Standard)
Circuit SPST
Contact Current(DC)-Max 0.1A
Sealing BOTTOM SEALED; TOP TAPE SEALED
Contact Voltage(DC)-Max 20V
Electrical Life 1,000 Cycles
Switch Type SLIDE DIP SWITCH
Number of Switch Sections 4
Washable Yes
Actuator Level Raised
Dimensions
Length 0.458 11.63mm
Body Height 3.8mm
Height Above Board 0.190 4.83mm
Compliance
RoHS Status RoHS Compliant
