210-3MSF
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Slide (Standard) 210 3 Through Hole Dip Switch 0.190 4.83mm 0.1A 20V -40C~85C
PDF
/
Inventory: 2209
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Beryllium Copper
Mounting Type Through Hole
Surface Mount NO
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2016
Series 210
Feature Epoxy Sealed Terminals
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Number of Positions 3
Voltage - Rated 20VDC
Current Rating (Amps) 100mA
Pitch 0.100 2.54mm Full
Contact Finish Gold
Termination Style PC Pin
Body Breadth 6.7 mm
Actuator Type Slide (Standard)
Circuit SPST
Contact Current(DC)-Max 0.1A
Sealing BOTTOM SEALED
Contact Voltage(DC)-Max 20V
Electrical Life 1,000 Cycles
Switch Type SLIDE DIP SWITCH
Number of Switch Sections 3
Washable No
Actuator Level Raised
Dimensions
Length 0.358 9.09mm
Height Above Board 0.190 4.83mm
Compliance
RoHS Status RoHS Compliant
