209-8LPST
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Switch DIP ON OFF SPST 8 Flush Slide 0.1A 20VDC PC Pins 2000Cycles 2.54mm Thru-Hole Tube
PDF
/
Buying Options
Total Price: USD $0.94
Unit Price: USD $0.9416
≥1 USD $0.9416
≥10 USD $0.9064
≥100 USD $0.852544
≥500 USD $0.736296
≥1000 USD $0.671018
≥3000 USD $0.623867
Inventory: 1104
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Beryllium Copper
Mounting Type Through Hole
Surface Mount NO
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2008
Series 209
JESD-609 Code e4
Feature Epoxy Sealed Terminals, Tape Seal
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Actuator Level Flush, Recessed
Washable Yes
Number of Switch Sections 8
Switch Type SLIDE DIP SWITCH
Electrical Life 2,000 Cycles
Contact Voltage(DC)-Max 20V
Sealing BOTTOM SEALED; TOP TAPE SEALED
Contact Current(DC)-Max 0.1A
Circuit SPST
Actuator Type Slide (Standard)
Body Breadth 6.7 mm
Termination Style PC Pin
Contact Finish Gold
Pitch 0.100 2.54mm Full
Current Rating (Amps) 100mA
Voltage - Rated 20VDC
Number of Positions 8
ECCN Code EAR99
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Above Board 0.180 4.57mm
Length 0.858 21.80mm
