209-4ESD
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Slide (Standard) 209 4 Through Hole Dip Switch 3.8mm 0.1A 20V -40C~85C
PDF
/
Buying Options
Total Price: USD $1.04
Unit Price: USD $1.035878
≥1 USD $1.035878
≥180 USD $0.413564
≥495 USD $0.400435
≥990 USD $0.39387
Inventory: 7704
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Beryllium Copper
Mounting Type Through Hole
Surface Mount NO
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2008
Series 209
JESD-609 Code e4
Feature Epoxy Sealed Terminals
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Number of Positions 4
Voltage - Rated 20VDC
HTS Code 8536.50.90.65
Current Rating (Amps) 100mA
Pitch 0.100 2.54mm Full
Contact Finish Gold
Termination Style PC Pin
Body Breadth 6.7 mm
Actuator Type Slide (Standard)
Circuit SPST
Contact Current(DC)-Max 0.1A
Sealing BOTTOM SEALED
Contact Voltage(DC)-Max 20V
Electrical Life 2,000 Cycles
Switch Type SLIDE DIP SWITCH
Number of Switch Sections 4
Washable No
Actuator Level Raised
Dimensions
Length 0.458 11.63mm
Body Height 3.8mm
Height Above Board 0.204 5.18mm
Compliance
RoHS Status RoHS Compliant
