209-2MSFD
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Slide (Standard) 209 2 Through Hole Dip Switch 3.8mm 0.1A 20VDC -40C~85C
PDF
/
Inventory: 5912
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Beryllium Copper
Mounting Type Through Hole
Surface Mount NO
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2008
Series 209
JESD-609 Code e3
Feature Epoxy Sealed Terminals
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Number of Positions 2
Terminal Finish Tin (Sn)
Voltage - Rated 20VDC
HTS Code 8536.50.90.65
Current Rating (Amps) 100mA
Pitch 0.100 2.54mm Full
Contact Finish Gold
Termination Style PC Pin
Body Breadth 6.55 mm
Actuator Type Slide (Standard)
Circuit SPST
Contact Current(DC)-Max 0.1A
Sealing BOTTOM SEALED
Electrical Life 2,000 Cycles
Switch Type SLIDE DIP SWITCH
Number of Switch Sections 2
Washable No
Actuator Level Raised
Dimensions
Length 0.258 6.55mm
Body Height 3.8mm
Height Above Board 0.190 4.83mm
Compliance
RoHS Status RoHS Compliant
