209-12ESFD image
Favorite
209-12ESFD image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Switches / DIP Switches
Description Slide (Standard) 209 12 Through Hole Dip Switch 3.8mm 0.1A 20V -40C~85C
PDF
/
Inventory: 1830
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 8 Weeks

Physical

Contact Material Beryllium Copper
Mounting Type Through Hole
Surface Mount NO

Technical

Operating Temperature -40°C~85°C
Packaging Tube
Published 2008
Series 209
JESD-609 Code e3
Feature Epoxy Sealed Terminals
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Number of Positions 12
Terminal Finish Tin (Sn)
Voltage - Rated 20VDC
HTS Code 8536.50.90.65
Current Rating (Amps) 100mA
Pitch 0.100 2.54mm Full
Contact Finish Gold
Termination Style PC Pin
Body Breadth 6.7 mm
Actuator Type Slide (Standard)
Circuit SPST
Contact Current(DC)-Max 0.1A
Sealing BOTTOM SEALED
Contact Voltage(DC)-Max 20V
Electrical Life 2,000 Cycles
Switch Type SLIDE DIP SWITCH
Number of Switch Sections 12
Washable No
Actuator Level Raised

Dimensions

Length 1.258 31.95mm
Body Height 3.8mm
Height Above Board 0.204 5.18mm

Compliance

RoHS Status RoHS Compliant
