208-3LPST
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Switch DIP OFF ON SPST 3 Flush Slide 0.05A 24VDC PC Pins 2.54mm Thru-Hole Tube
PDF
/
Buying Options
Total Price: USD $1.16
Unit Price: USD $1.161917
≥1 USD $1.161917
≥220 USD $0.464767
≥495 USD $0.449012
≥990 USD $0.441134
Inventory: 4910
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Above Board 0.299 7.60mm
Body Height 7.6mm
Length 0.386 9.80mm
Technical
Actuator Level Flush, Recessed
Washable Yes
Number of Switch Sections 3
Switch Type SLIDE DIP SWITCH
Electrical Life 2,000 Cycles
Contact Voltage(DC)-Max 24V
Sealing EPOXY TERMINAL SEALED; TOP TAPE SEALED
Contact Current(DC)-Max 0.05A
Circuit SPST
Actuator Type Slide (Standard)
Body Breadth 9.78 mm
Termination Style PC Pin
Contact Finish Tin
Pitch 0.100 2.54mm Full
Current Rating (Amps) 50mA
Additional Feature LOW PROFILE
Voltage - Rated 24VDC
Number of Positions 3
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Epoxy Sealed Terminals, Tape Seal
JESD-609 Code e3
Series 208
Published 2010
Packaging Tube
Operating Temperature -55°C~85°C
Physical
Body Material Plastic
Surface Mount NO
Mounting Type Through Hole
Supply Chain
Factory Lead Time 8 Weeks
