206-8S
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Switch DIP OFF ON SPST 8 Raised Slide 0.05A 24VDC PC Pins 2.54mm Thru-Hole Tube
PDF
/
Inventory: 6935
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Above Board 0.334 8.48mm
Body Height 7.6mm
Length 0.886 22.50mm
Technical
Actuator Level Raised
Washable No
Contact Function OFF-ON
PCB Hole Count 16
Number of Switch Sections 8
Switch Type SLIDE DIP SWITCH
Electrical Life 10,000 Cycles
Dielectric Withstanding Voltage 500VAC V
Contact Voltage(DC)-Max 24V
Sealing EPOXY TERMINAL SEALED; TOP TAPE SEALED
Contact Current(DC)-Max 0.05A
Insulation Resistance 1000000000Ohm
Circuit SPST
Actuator Type Slide (Standard)
Termination Style PC Pin
Contact Finish Gold
Pitch 0.100 2.54mm Full
Current Rating (Amps) 50mA
Voltage - Rated 24VDC
Terminal Finish Matte Tin (Sn) - reflowed over Nickel (Ni) barrier
Number of Positions 8
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Epoxy Sealed Terminals
JESD-609 Code e3
Series 206
Published 2010
Packaging Tube
Operating Temperature -55°C~85°C
Physical
End Contact Material COPPER ALLOY
Terminal Material COPPER ALLOY
Center Contact Material COPPER ALLOY
Body Material Plastic
Surface Mount NO
Mounting Type Through Hole
Supply Chain
Factory Lead Time 8 Weeks
