206-216RA
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Switch DIP OFF ON DPST 6 Raised Slide 0.05A 24VDC PC Pins 2.54mm Thru-Hole Tube
PDF
/
Inventory: 4152
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Above Board 0.400 10.16mm
Length 1.286 32.66mm
Technical
Actuator Level Raised
Washable No
Number of Switch Sections 6
Switch Type SLIDE DIP SWITCH
Electrical Life 10,000 Cycles
Contact Voltage(DC)-Max 24V
Contact Current(DC)-Max 0.05A
Circuit DPST
Actuator Type Slide (Standard)
Body Breadth 7.24 mm
Termination Style PC Pin
Contact Finish Gold
Pitch 0.100 2.54mm Full
Current Rating (Amps) 50mA
Voltage - Rated 24VDC
Number of Positions 6
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 206RA
Published 2009
Packaging Tube
Operating Temperature -55°C~85°C
Physical
Body Material Plastic
Mounting Feature THROUGH HOLE-RIGHT ANGLE
Surface Mount NO
Mounting Type Through Hole, Right Angle
Supply Chain
Factory Lead Time 8 Weeks
