206-215S
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Switch DIP OFF ON DPST 5 Raised Slide 0.05A 24VDC PC Pins 2.54mm Thru-Hole Tube
PDF
/
Buying Options
Total Price: USD $2.55
Unit Price: USD $2.545713
≥1 USD $2.545713
≥200 USD $1.016185
≥500 USD $0.982049
≥1000 USD $0.964982
Inventory: 8307
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mounting Type Through Hole
Surface Mount NO
Body Material Plastic
Technical
Operating Temperature -55°C~85°C
Packaging Tube
Published 2010
Series 206
JESD-609 Code e4
Feature Epoxy Sealed Terminals
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Number of Positions 5
Voltage - Rated 24VDC
Current Rating (Amps) 50mA
Pitch 0.100 2.54mm Full
Contact Finish Gold
Termination Style PC Pin
Body Breadth 9.78 mm
Actuator Type Slide (Standard)
Circuit DPST
Sealing EPOXY TERMINAL SEALED; TOP TAPE SEALED
Contact Voltage(DC)-Max 24V
Electrical Life 10,000 Cycles
Switch Type SLIDE DIP SWITCH
Number of Switch Sections 5
Washable No
Actuator Level Raised
Dimensions
Length 1.086 27.58mm
Body Height 7.6mm
Height Above Board 0.334 8.48mm
Compliance
RoHS Status RoHS Compliant
