206-215RAST
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Slide (Standard) 206RA 5 Through Hole Right Angle Dip Switch 7.62mm 50mA 24V -55C~85C
PDF
/
Inventory: 10043
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Above Board 0.400 10.16mm
Body Height 7.62mm
Length 1.086 27.58mm
Technical
Actuator Level Raised
Washable Yes
Number of Switch Sections 5
Switch Type SLIDE DIP SWITCH
Electrical Life 10,000 Cycles
Contact Voltage(DC)-Max 24V
Sealing BOTTOM SEALED; TOP TAPE SEALED
Circuit DPST
Actuator Type Slide (Standard)
Body Breadth 9.78 mm
Termination Style PC Pin
Contact Finish Gold
Pitch 0.100 2.54mm Full
Current Rating (Amps) 50mA
Voltage - Rated 24VDC
Terminal Finish TIN
Number of Positions 5
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals, Tape Seal
JESD-609 Code e3
Series 206RA
Published 2009
Packaging Tube
Operating Temperature -55°C~85°C
Physical
Body Material Plastic
Mounting Feature THROUGH HOLE-RIGHT ANGLE
Surface Mount NO
Mounting Type Through Hole, Right Angle
Supply Chain
Factory Lead Time 8 Weeks
