206-126ST
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Switch DIP OFF ON SPDT 6 Raised Slide 0.05A 24VDC PC Pins 2.54mm Thru-Hole Tube
PDF
/
Buying Options
Total Price: USD $3.15
Unit Price: USD $3.149647
≥1 USD $3.149647
≥195 USD $1.256445
≥495 USD $1.214433
≥1005 USD $1.194739
Inventory: 4673
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mounting Type Through Hole
Surface Mount NO
Body Material Plastic
Technical
Operating Temperature -55°C~85°C
Packaging Tube
Published 2010
Series 206
JESD-609 Code e4
Feature Epoxy Sealed Terminals, Tape Seal
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Number of Positions 6
Voltage - Rated 24VDC
Current Rating (Amps) 50mA
Pitch 0.100 2.54mm Full
Contact Finish Gold
Termination Style PC Pin
Body Breadth 9.78 mm
Actuator Type Slide (Standard)
Circuit SPDT
Contact Current(DC)-Max 0.05A
Sealing EPOXY TERMINAL SEALED; TOP TAPE SEALED
Contact Voltage(DC)-Max 24V
Electrical Life 10,000 Cycles
Switch Type SLIDE DIP SWITCH
Number of Switch Sections 6
Washable Yes
Actuator Level Raised
Dimensions
Length 1.286 32.66mm
Height Above Board 0.334 8.48mm
Compliance
RoHS Status RoHS Compliant
