206-124RAST
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Slide (Standard) 206RA 4 Through Hole Right Angle Dip Switch 7.62mm 0.05A 24VDC -55C~85C
PDF
/
Buying Options
Total Price: USD $2.9
Unit Price: USD $2.902822
≥1 USD $2.902822
≥200 USD $1.159291
≥500 USD $1.119904
≥1000 USD $1.101523
Inventory: 1922
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Above Board 0.400 10.16mm
Body Height 7.62mm
Length 0.886 22.50mm
Technical
Actuator Level Raised
Washable Yes
Number of Switch Sections 4
Switch Type SLIDE DIP SWITCH
Electrical Life 10,000 Cycles
Sealing BOTTOM SEALED; TOP TAPE SEALED
Contact Current(DC)-Max 0.05A
Circuit SPDT
Actuator Type Slide (Standard)
Body Breadth 9.78 mm
Termination Style PC Pin
Contact Finish Gold
Pitch 0.100 2.54mm Full
Current Rating (Amps) 50mA
HTS Code 8536.50.90.65
Voltage - Rated 24VDC
Terminal Finish TIN
Number of Positions 4
ECCN Code EAR99
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Epoxy Sealed Terminals, Tape Seal
JESD-609 Code e3
Series 206RA
Published 2009
Packaging Tube
Operating Temperature -55°C~85°C
Physical
Body Material Plastic
Mounting Feature THROUGH HOLE-RIGHT ANGLE
Surface Mount NO
Mounting Type Through Hole, Right Angle
Supply Chain
Factory Lead Time 8 Weeks
