206-12
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
SWITCH SLIDE DIP SPST 50MA 24V
PDF
/
Inventory: 1759
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mounting Type Through Hole
Surface Mount NO
Body Material Plastic
Technical
Operating Temperature -55°C~85°C
Packaging Tube
Published 2010
Series 206
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
ECCN Code EAR99
Number of Positions 12
Voltage - Rated 24VDC
HTS Code 8536.50.90.65
Current Rating (Amps) 50mA
Pitch 0.100 2.54mm Full
Contact Finish Gold
Termination Style PC Pin
Body Breadth 9.78 mm
Actuator Type Slide (Standard)
Circuit SPST
Contact Current(DC)-Max 0.05A
Contact Voltage(DC)-Max 24V
Electrical Life 10,000 Cycles
Switch Type SLIDE DIP SWITCH
Number of Switch Sections 12
Washable No
Actuator Level Raised
Dimensions
Length 1.286 32.66mm
Body Height 7.6mm
Height Above Board 0.334 8.48mm
Compliance
RoHS Status RoHS Compliant
