206-10S
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Switch DIP OFF ON SPST 10 Raised Slide 0.05A 24VDC PC Pins 2.54mm Thru-Hole Tube
PDF
/
Inventory: 4742
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Above Board 0.334 8.48mm
Body Height 7.6mm
Length 1.086 27.58mm
Technical
Actuator Level Raised
Washable No
Number of Switch Sections 10
Switch Type SLIDE DIP SWITCH
Electrical Life 10,000 Cycles
Contact Voltage(DC)-Max 24V
Sealing EPOXY TERMINAL SEALED; TOP TAPE SEALED
Contact Current(DC)-Max 0.05A
Circuit SPST
Actuator Type Slide (Standard)
Body Breadth 9.78 mm
Termination Style PC Pin
Contact Finish Gold
Pitch 0.100 2.54mm Full
Current Rating (Amps) 50mA
HTS Code 8536.50.90.65
Voltage - Rated 24VDC
Terminal Finish Tin (Sn)
Number of Positions 10
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Epoxy Sealed Terminals
JESD-609 Code e3
Series 206
Published 2010
Packaging Tube
Operating Temperature -55°C~85°C
Physical
Body Material Plastic
Surface Mount NO
Mounting Type Through Hole
Supply Chain
Factory Lead Time 8 Weeks
