206-10ES
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Switch DIP OFF ON SPST 10 Extended Slide 0.05A 24VDC PC Pins 2.54mm Thru-Hole Tube
PDF
/
Inventory: 7957
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Above Board 0.434 11.02mm
Length 1.086 27.58mm
Technical
Actuator Level Raised
Washable No
Electrical Life 10,000 Cycles
Circuit SPST
Actuator Type Slide (Standard)
Termination Style PC Pin
Contact Finish Gold
Pitch 0.100 2.54mm Full
Current Rating (Amps) 50mA
Voltage - Rated 24VDC
Number of Positions 10
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
Series 206
Published 2010
Packaging Tube
Operating Temperature -55°C~85°C
Physical
Body Material Plastic
Mounting Type Through Hole
Supply Chain
Factory Lead Time 8 Weeks
