193-9MSN
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Switch DIP ON OFF SPST 9 Piano 0.05A 24VDC Gull Wing SMD Tube
PDF
/
Inventory: 2291
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Above Board 0.359 9.12mm
Length 0.986 25.04mm
Technical
Actuator Level Raised
Washable No
Number of Switch Sections 9
Electrical Life 7,000 Cycles
Dielectric Withstanding Voltage 500VAC V
Contact Voltage(DC)-Max 24V
Sealing EPOXY TERMINAL SEALED
Contact Current(DC)-Max 0.05A
Insulation Resistance 1000000000Ohm
Contact Resistance 0.1mOhm
Circuit SPST
Actuator Type Piano
Termination Style Gull Wing
Contact Finish Gold
Pitch 0.100 2.54mm Full
Current Rating (Amps) 50mA
Additional Feature SHIP AT ON POSITION
Voltage - Rated 24VDC
Terminal Finish Tin (Sn)
Number of Positions 9
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Epoxy Sealed Terminals
JESD-609 Code e3
Series 193
Published 2014
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Body Material Plastic
Mounting Feature SURFACE MOUNT-STRAIGHT
Surface Mount NO
Mounting Type Surface Mount, Right Angle
Supply Chain
Factory Lead Time 8 Weeks
