TDA02H0SB1
RoHS
RoHS compliant
RoHS compliantPackage DIP
Category Switches / DIP Switches
Description
Slide (Standard) TDA 2 Surface Mount Dip Switch 0m 25mA 24V 100mOhm
PDF
/
Buying Options
Total Price: USD $2.37
Unit Price: USD $2.3672
≥1 USD $2.3672
≥10 USD $2.23608
≥100 USD $2.032448
≥500 USD $1.761549
≥1000 USD $1.597024
≥3000 USD $1.480899
Inventory: 1174
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Height Above Board 0.091 2.30mm
Actuator Length 0m
Length 0.144 3.67mm
Technical
Actuator Level Flush, Recessed
Washable Yes
Contact Current Rating 25mA
Lead/Base Style Gull Wing
Mechanical Life 1,000 Cycles
Max Voltage Rating (DC) 24V
Number of Poles 2
Electrical Life 1,000 Cycles
Max Current Rating 25mA
Contact Resistance 100mOhm
Circuit SPST
Actuator Type Slide (Standard)
Termination Style Gull Wing
Contact Finish Gold
Current Rating 25mA
Depth 8.12mm
Terminal Pitch 1.27mm
Orientation Straight
Pitch 0.050 1.27mm Half
Voltage - Rated DC 24V
Voltage - Rated 24VDC
Termination Gull Wing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Tape Seal
Series TDA
Published 2006
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Actuator Material Polymer
Body Material Polyphenylene Sulfide (PPS)
Package / Case DIP
Mounting Type Surface Mount
Mount Surface Mount
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 17 Weeks
