SP02AB
RoHS
/
Package /
Category Switches / DIP Switches
Description
SWITCH SLIDE DIP SPST 10MA 20V
PDF
/
Buying Options
Total Price: USD $5.05
Unit Price: USD $5.049413
≥1 USD $5.049413
≥200 USD $2.015302
≥500 USD $1.948344
≥1000 USD $1.914208
Inventory: 10041
Minimum: 1
-
+
Technical Details
Physical
Contact Material Beryllium Copper
Contact Plating Gold
Mount Through Hole
Mounting Type Through Hole, Right Angle
Body Material Polyphenylene Sulfide (PPS)
Technical
Operating Temperature -20°C~85°C
Packaging Tube
Published 2006
Series SP
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Through Hole
Number of Positions 2
Max Operating Temperature 85°C
Min Operating Temperature -20°C
Voltage - Rated 20VDC
Voltage - Rated DC 20V
Current Rating (Amps) 10mA
Pitch 0.100 2.54mm Full
Orientation Right Angle
Terminal Pitch 2.54mm
Current Rating 10mA
Contact Finish Gold
Termination Style PC Pin
Actuator Type Slide (Standard)
Circuit SPST
Max Current Rating 10mA
Electrical Life 1,000 Cycles
Throw Configuration SPST
Mechanical Life 1,000 Cycles
Washable Yes
Actuator Level Flush, Recessed
Dimensions
Length 0.298 7.58mm
Height Above Board 0.169 4.30mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Lead Free
