SDA05H0SK
RoHS
/
Package DIP
Category Switches / DIP Switches
Description
DIP Switches / SIP Switches FLUSH ACT 5 POS
PDF
/
Buying Options
Total Price: USD $3.54
Unit Price: USD $3.542204
≥1 USD $3.542204
≥210 USD $1.413993
≥510 USD $1.366729
≥990 USD $1.343097
Inventory: 6983
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Material Beryllium Copper
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case DIP
Body Material Polyphthalamide (PPA)
Technical
Operating Temperature -20°C~85°C
Packaging Tube
Published 2001
Series SDA
Feature Tape Seal
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Gull Wing
Number of Positions 5
Max Operating Temperature 85°C
Min Operating Temperature -20°C
Voltage - Rated 24VDC
Voltage - Rated DC 24V
Current Rating (Amps) 25mA
Pitch 0.100 2.54mm Full
Terminal Pitch 2.54mm
Current Rating 25mA
Contact Finish Gold
Termination Style Gull Wing
Actuator Type Slide (Standard)
Circuit SPST
Electrical Life 1,000 Cycles
Throw Configuration SPST
Max Voltage Rating (DC) 50V
Mechanical Life 1,000 Cycles
Washable Yes
Actuator Level Flush, Recessed
Dimensions
Length 0.578 14.68mm
Height Above Board 0.175 4.45mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
