SDA05H0BD
RoHS
RoHS compliant
RoHS compliantPackage DIP
Category Switches / DIP Switches
Description
SW DIP TOP SLIDE FLUSH 5POS 24V
PDF
/
Buying Options
Total Price: USD $1.94
Unit Price: USD $1.9448
≥1 USD $1.9448
≥10 USD $1.892
≥100 USD $1.72069
≥500 USD $1.4949
≥1000 USD $1.354742
≥3000 USD $1.261313
Inventory: 800
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height Above Board 0.183 4.65mm
Actuator Length 0m
Length 0.578 14.68mm
Technical
Actuator Level Flush, Recessed
Washable No
Mechanical Life 1,000 Cycles
Max Voltage Rating (DC) 24V
Electrical Life 1,000 Cycles
Max Current Rating 100mA
Contact Resistance 50mOhm
Circuit SPST
Actuator Type Slide (Standard)
Termination Style PC Pin
Contact Finish Gold
Current Rating 25mA
Terminal Pitch 2.54mm
Orientation Straight
Pitch 0.100 2.54mm Full
Voltage - Rated DC 24V
Voltage - Rated 24VDC
Number of Positions 5
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series SDA
Published 2012
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Actuator Material Polyamide
Body Material Polyphenylene Sulfide (PPS)
Package / Case DIP
Mounting Type Through Hole
Mount Through Hole
Contact Material Beryllium Copper
Supply Chain
Factory Lead Time 15 Weeks
