SDA03H1BD
RoHS
RoHS compliant
RoHS compliantPackage DIP
Category Switches / DIP Switches
Description
Switch DIP OFF ON SPST 3 Raised Slide 0.1A 24VDC PC Pins 1000Cycles 2.54mm Thru-Hole Tube
PDF
/
Buying Options
Total Price: USD $1.29
Unit Price: USD $1.2936
≥1 USD $1.2936
≥10 USD $1.23992
≥100 USD $1.165507
≥500 USD $1.006782
≥1000 USD $0.917514
≥3000 USD $0.853028
Inventory: 1122
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Contact Material Beryllium Copper
Mount Through Hole
Mounting Type Through Hole
Package / Case DIP
Body Material Polyphenylene Sulfide (PPS)
Actuator Material Polyamide
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2004
Series SDA
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
Number of Positions 3
Voltage - Rated 24VDC
Voltage - Rated DC 24V
Pitch 0.100 2.54mm Full
Orientation Straight
Terminal Pitch 2.54mm
Depth 8.38mm
Current Rating 25mA
Contact Finish Gold
Termination Style PC Pin
Actuator Type Slide (Standard)
Circuit SPST
Contact Resistance 50mOhm
Max Current Rating 100mA
Electrical Life 1,000 Cycles
Max Voltage Rating (DC) 24V
Mechanical Life 1,000 Cycles
Washable No
Actuator Level Raised
Dimensions
Length 0.378 9.60mm
Actuator Length 1mm
Height Above Board 0.228 5.80mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
